5.2.18 F24: Parameter for Lifting
Ref. code Name Description Setting Range [Default]
F24.00 Starting frequency 0 - Min (F24.02,F24.09) [0.50Hz]
F24.01 Starting frequency delay time 0.00 - 9.99 [0.1s]
After start command is valid, inverter runs at F24.00, wait until F24.01 is finished, and continue to run
according to setting frequency.
F24.02 UP brake releasing frequency F24.00 - F24.04 [2.00Hz]
F24.03 UP brake releasing current
0.0 - 100.0 (rated current of
motor) [0.00%]
F24.04 UP brake releasing delay frequency F24.02 - 20.00 [3.00Hz]
F24.05 UP brake releasing delay time 0.00 - 9.99 [0.3s]
F24.06 UP brake closing frequency F24.07 - 20.00 [3.00Hz]
F24.07 UP sliding prevention frequency 0.00 - F24.06 [2.50Hz]
F24.08 UP sliding prevention delay time 0.00 - 9.99 [0.3s]
F24.09 DN brake releasing frequency F24.00 - F24.11 [2.00Hz]
F24.10 DN brake releasing current
0.0 - 100.0 (rated current of
motor) [0.00%]
F24.11 DN brake releasing delay frequency F24.09 - 20.00 [3.00Hz]
F24.12 DN brake releasing delay time 0.00 - 9.99 [0.3s]
F24.13 DN brake closing frequency F24.14 - 20.00 [3.00Hz]
F24.14 DN sliding prevention frequency 0.00 - F24.13 [2.50Hz]
F24.15 DN sliding prevention delay time 0.00 - 9.99 [0.3s]
F24.02 - F24.08 is UP brake parameter, F24.09 - F24.15 is DN brake parameter.
When going UP:
• When frequency = F24.02, output current = F24.03, and output torque = F24.29, brake output terminal
outputs releasing signal;
• When frequency < F24.06, brake output terminal outputs closing signal.
When going down:
• When frequency F24.09, output current = F24.10, and output torque = F24.30, brake output terminal
outputs releasing signal;
• When frequency < F24.13, brake output terminal outputs closing signal.
