Chapter 5 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
―44― HD3N-TC Series Inverter User Manual V1.0
5.2.10 F13: Asyn. Motor 2 Parameter
F13 set parameter of motor 2 and its control parameter. It corresponds to motor 1 parameter, refer to
motor 1. F13 can achieve switching between 2 motors (refer to No. 47 function in DI terminal).
Check F08: Asyn. Motor 1 Parameter for F13.01 - F13.12.
Check F09: Motor 1 V/f Control Parameters for F13.16 - F13.32, F13.58 - F13.68.
Check F10: Motor 1 Vector Control Speed-loop Parameters for F13.35 - F13.49.
Check F11: Motor 1 Vector Control Current-loop Parameters for F13.50 - F13.57.
Ref. code Name Description Setting Range [Default]
F13.00 Motor 2 control mode 0 - 6 [0]
0: V/f control without PG.
1: Vector control 1without PG.
2,6: Vector control 2/3 without PG.
F13.01 Rated power of motor 2 0.2 - 500.0kW
[Depend on model]
F13.02 Rated voltage of motor 2 0 - 999V [Depend on model]
F13.03 Rated current of motor 2 0.1 - 999.9A [Depend on model]
F13.04 Rated frequency of motor 2 1.0 - 400.0 [50.0Hz]
F13.05 Rated Rpm of motor 2 1 - 24000rpm [Depend on
model]
F13.07 Parameter auto-tuning of motor 2 0 - 3 [0]
0: No action.
1: Stationary auto-tuning.
2: Rotary auto-tuning.
3: Motor stator resistance measurement.
F13.08 Stator resistance of motor 2 0.000 - 9.999Ω
[Depend on model]
F13.09 Rotor resistance of a motor 2
F13.10 Leakage inductance of motor 2 0.00 - 500.00mH
[Depend on model]
F13.11 Mutual inductance of motor 2
F13.12 Excitation current of motor 2 0.0 - 999.9A [Depend on model]
F13.16 V/f curve of motor 2 0 - 4 [0]
0: Line.
1: Square curve.
2: 1.2 exponential curve.
3: 1.7 exponential curve.
4: User-defined curve.
F13.17 V/f frequency of motor 2 (F3) F13.19 - 100.0 [0.0%]
F13.18 V/f voltage of motor 2 (V3) F13.20 - 100.0 [0.0%]
F13.19 V/f frequency of motor 2 (F2) F13.21 - F13.17 [0.0%]
F13.20 V/f voltage of motor 2 (V2) F13.22 - F13.18 [0.0%]
F13.21 V/f frequency of motor 2 (F1) 0.0 - F13.19 [0.0%]
F13.22 V/f voltage of motor 2 (V1) 0.0 - F13.20 [0.0%]
