hpmont HD3N-TC Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 5 Function Introduction
HD3N-TC Series Inverter User Manual V1.0 ―45―
Ref. code Name Description Setting Range [Default]
F13.23 Torque boost of motor 2 0.0 - 30.0 [2.0%]
F13.24 Cut-off point used for manual torque boost of motor 2 0.0 - 50.0 (F13.04) [25.0%]
F13.25 Slip compensation gain of motor 2 0.0 - 300.0 [100.0%]
F13.26 Slip compensation filter time of motor 2 0.01 - 10.00 [0.10s]
F13.27 Slip compensation limit of motor 2 0.0 - 250.0 [200.0%]
F13.28 Motor 2 iron loss 0.000 - 9.999kW
[Depend on model]
F13.30 AVR (automatic voltage regulation) function of motor 2 0 - 2 [1]
0: Disabled.
1: Enabled all the time.
2: Disabled in Dec process.
F13.31 Low frequency oscillation-suppression of motor 2 0 - 200 [50]
F13.32 High frequency oscillation-suppression of motor 2 0 - 200 [20]
F13.35 Proportional gain 1 of motor 2 speed control 0.1 - 200.0 [10.0]
F13.36 Integral time 1 of motor 2 speed control 0.00 - 10.00 [0.10s]
F13.37 Proportional gain 2 of motor 2 speed control 0.1 - 200.0 [10.0]
F13.38 Integral time 2 of motor 2 speed control 0.00 - 10.00 [0.20s]
F13.39 Switching frequency 1 of motor 2 speed loop 0.00 - 50.00 [10.00Hz]
F13.40 Switching frequency 2 of motor 2 speed loop 0.00 - 50.00 [15.00Hz]
F13.41 ASR integral limit of motor 2 0.0 - 200.0 (F13.03) [180.0%]
F13.42 Motor 2 speed loop differential time 0.00 - 1.00 [0.00s]
F13.43 Motor 2 speed loop output filter time 0.000 - 1.000 [0.000s]
F13.44 Locking selection for motor torque limit of motor 2 0,1 [0]
0: Do not lock.
1: All of the torque limit are same with FWD electric torque limit.
F13.45 Setting channel of motor 2 torque 0000 - 7777 [0000]
Units: Electric torque limit channel when motor is FWD
Tens: Electric torque limit channel when motor is REV
Hundreds: Braking torque limit channel when motor is FWD
Thousands: Braking torque limit channel when motor is REV
• 0: Limit by digital setting.
• 3 - 4: AI1 - AI2.
• 7: Potentionmeter. Valid when LED keypad adopted only.
F13.46 Electric torque limit when motor 2 is FWD
0.0 - 200.0 (F13.03) [180.0%]
F13.47 Electric torque limit when motor 2 is REV
F13.48 Braking torque limit when motor 2 is FWD
F13.49 Braking torque limit when motor 2 is REV
