hpmont HD3N-TC Series User Manual

Chapter 5 Function Introduction Shenzhen Hpmont Technology Co., Ltd.
―46― HD3N-TC Series Inverter User Manual V1.0
Ref. code Name Description Setting Range [Default]
F13.50 Current-loop KP of motor 2 1 - 2000 [800]
F13.51 Current-loop KI of motor 1 - 1000 [200]
F13.52 Current-loop output filter times of motor 2 0 - 31 [3]
F13.55 Enable feedforward of motor 2 current-loop 0,1 [0]
0: Forbid feedforward.
1: Enable feedforward.
F13.56 Motor 2 excitation boost setting 0.0 - 30.0 [0.0%]
F13.57 To optimize motor magnatic field orientation of motor 2 0,1 [0]
0: Prohibit.
1: Enable.
F13.58 V/f frequency of special motor 2 (F3) F13.60 - 100.0 [100.0%]
F13.59 V/f voltage of special motor 2 (V3) F13.61 - 100.0 [100.0%]
F13.60 V/f frequency of special motor 2 (F2) F13.62 - F13.58 [40.0%]
F13.61 V/f voltage of special motor 2 (V2) F13.63 - F13.59 [42.0%]
F13.62 V/f frequency of special motor 2 (F1) 0.0 - F13.60 [10.0%]
F13.63 V/f voltage of motor (V1) 0.0 - F13.61 [12.0%]
F13.64 Slip compensation gain of motor 2 (low speed) 0.0 - 300.0 [0.0%]
F13.65 Slip compensation gain of motor 2 (high speed) 0.0 - 300.0 [100.0%]
F13.66 Slip compensation switching frequency 1 of motor 2 0.00 - F13.67 [5.00Hz]
F13.67 Slip compensation switching frequency 2 of motor 2 F13.66 - F13.04 [10.00Hz]
F13.68 Slip compensation selection of motor 2 00 - 11 [11]
Units: UP slip compensation selection
Tens: DN slip compensation selection
• 0: Set by F13.64.
• 1: Set by F13.64 - F13.65.
