Shenzhen Hpmont Technology Co., Ltd. Chapter 5 Function Introduction
HD3N-TC Series Inverter User Manual V1.0 29
Ref. code Name Description Setting Range [Default]
d00.15 Setting frequency (after Acc/Dec) (Hz) [Actual value]
Display the setting frequency after acc/dec.
d00.16 Output frequency (Hz) [Actual value]
d00.17 Setting rpm (rpm) [Actual value]
d00.18 Running rpm (rpm) [Actual value]
d00.20 Output voltage (V) [Actual value]
d00.21 Output current (A) [Actual value]
d00.23 Torque setting (%) [Actual value]
Display torque setting which is relative percentage of the rated torque.
d00.24 Output power (kW) [Actual value]
Display present actual output power.
d00.25 DC busbar voltage (V) [Actual value]
d00.26 Input voltage of potentionmeter (%) [Actual value]
Display input voltage of potentionmeter that is calculated by gain, bias and filter, relative percentage of 5V.
Valid when LED keypad adopted.
d00.27 AI1 input (%) [Actual value]
Display AI1 calculated by filter, percentage of 10V.
d00.28 AI1 input (after calculating) (%) [Actual value]
Display AI calculated by gain, bias and filter, percentage of 10V.
d00.29 AI2 input (%) [Actual value]
Display AI2 input voltage/current calculated by filter.
When AI2 selects voltage input, 0V corresponds to 0.0%, and 10V corresponds to 100.0%.
When AI2 selects current input, 0mA corresponds to 0.0%, 20mA corresponds to 100.0%.
d00.30 AI2 input (after calculating) (%) [Actual value]
Display AI2 input voltage/current which is calculated by gain and bias.
Refer to d00.29.
d00.36 AO1 output (%) [Actual value]
When AO1 selects voltage output, 0.0% corresponds to 0V, 100.0% corresponds to 10V.
When AO1 selects 0 - 20mA current output, 0.0% corresponds to 0mA, 100.0% corresponds to 20mA.
When AO1 selects 4 - 20mA current output, 0.0% corresponds to 4mA, 100.0% corresponds to 20mA.
Refer to F16.22 and F16.23 for setting of 4 - 20mA current output.
d00.37 AO2 output (%) [Actual value]
The relationship is same as AO1, refer to d00.36.
d00.38 High speed output pulse frequency (Hz) [Actual value]
d00.43 Load coefficient [Actual value]
Display load coefficient, relative to rated current of motor.
