Chapter 3 Electrical Installation Shenzhen Hpmont Technology Co., Ltd.
―8― HD3N-TC Series Inverter User Manual V1.0
Table 3-2 Supply and motor connection
Frame 1
Frame 2
Frame 3 / Frame 4
BR U V W PE
Supply
ground
L1 L2
L3/N
(+)
Braking
resistor
EMI filter
AC reactor
Mains supply
MCCB
Contactor
L1 L2
L3/N
(+) (-) BR U V W PE
Braking
resistor
Supply
ground
EMI filter
AC reactor
Mains supply
MCCB
Contactor
L1 L2 L3 (+) (-) BR U V WPE
Braking
resistor
Supply
ground
EMI filter
AC reactor
Mains supply
MCCB
Contactor
