Ref. code Name Description Setting Range [Default]
Steps:
1. Correctly set motor parameter (F08.00 - F08.04).
2. When F08.06 = 2, set proper acc time 1 (F03.01) and dec time 1 (F03.02), free motor axis from load and
make sure it is safe.
3. When F08.06 =1 or 2 or 3, press , then press button ( ) to exit to parameter display state,
and press button ( ) to start auto-tuning. LED keypad displays “tunE”.
4. When run command flahses on keypad, it means auto-tuning is finished and return to stop state display,
and F08.06 resumes 0.
F08.07 Stator resistance of motor 1 0.000 - 9.999Ω
[Depend on model]
F08.08 Rotor resistance of a motor 1
F08.09 Leakage inductance of motor 1 0.00 - 500.00mH
[Depend on model]
F08.10 Mutual inductance of motor 1
F08.11 Excitation current of motor 1 0.0 - 999.9A [Depend on model]
