Ref. code Name Description Setting Range [Default]
46: External reset (RST) input. Reset fault when inverter has fault.
• It has the same function as button ( ) on keypad.
47: Switch motor 1/2.
• When valid, switch two groups of motor.
200: UP limit switch input.
• When going up and detects up limit signal, inverter coast to stop and brake output signal outputs
brake closing signal. Now inverter supports DN signal only.
201: DN limit switch input.
• When going down and detect DN limit signal, inverter coast to stop and brake output signal outputs
brake closing signal. Now inverter supports UP signal only.
202,203: UP/DN final limit switch input.
• When detecting UP or DN final limit signal is valid, inverter coast to stop, and brake output signal
outputs brake closing signal. Now inverter supports neither UP nor DN signal. It will run after setting
this terminal to other functions.
204: Brake feedback input (NC contact).
F15.12 UP/DN acc/dec rate 0.00 - 99.99 [1.00Hz/s]
Defines setting frequency changing rate by UP/DN.
F15.13 Interval between terminal detection 0 - 2 [0]
0: 2ms.
1: 4ms.
2: 8ms.
F15.14 Terminal detection filter times 0 - 10000 [2]
Delay or confirm digital input signal in case of mal-function.
F15.15 Terminal input logic setting 0000 - 0x303F [0000]
Defines that each bit (binary) represents different physical sources.
• 0: Positive logic.
• Connected to corresponding common port: this logic is enabled. Otherwise disabled.
• Valid when AI input voltage ≥ 6V, invalid when AI input voltage ≤ 4V.
• 1: Negative logic.
• Connected to corresponding common port: this logic is disabled. Otherwise enabled.
• Valid when AI input voltage < 4V, invalid when AI input voltage > 6V.
F15.15
Thousands Tens Units
Bit13 Bit12 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Frame3 / 4 AI2 AI1 DI6 DI5 DI4 DI3 DI2 DI1
Frame1 / 2 AI DI4 DI3 DI2 DI1
