hpmont HD3N-TC Series User Manual

Shenzhen Hpmont Technology Co., Ltd. Chapter 5 Function Introduction
HD3N-TC Series Inverter User Manual V1.0 ―63―
Ref. code Name Description Setting Range [Default]
F24.23 The detection selection of lack of output 0,1 [0]
0: Detect only when lack of one phase.
1: Detect as long as lack of output.
F24.24 The detection frequency of lack of output 0.00 - 20.00 [5.00Hz]
Refer to F20.10 - F20.11.
F24.25 Brake feedback detection time 0.00 - 9.99 [0.5s]
Inverter judges it as abnormal when time of not detecting brake feedback signal>F24.25, and report E0030
(brake fault).
• F24.25 = 0 or DI ≠ No. 204, brake fault is invalid.
F24.27 Detection time for brake releasing 0.00 - 9.99 [1.0s]
When inverter finished the time of F24.27, inverter reports E0032 (brake releasing is abnormal).
• F24.27 = 0, E0032 is invalid.
F24.28 Stop mode 0,1 [0]
0: Decelerate to stop.
1: Coast to stop.
F24.29 UP brake releasing torque 0.0 - 100.0 (rated torque of
motor) [0.00%]
F24.30 DN brake releasing torque 0.0 - 100.0 (rated torque of
motor) [0.00%]
