HM-E200 Programming Manual
42
GS ( k p L p H cn fn m (cn = 48, fn = 82)
[Name] PDF417: Transmit the size information of the symbol data in the symbol storage area
[Format] ASCII GS ( k p L p H cn fn m
Hex 1D 28 6B p L p H cn fn m
Decimal 29 40 107 p L p H cn fn m
[Range] ( p L + p H × 256) = 3 ( p L = 3, p H = 0)
cn = 48
fn = 82
m = 48
[Description] • Transmits the size information for t he encoded PDF417 symbol data in the symbol
storage area with GS ( k <Function 080>.
[Notes] • This function does not print.
• The size information does not include the quiet zone (left, right, upward, and
downward space areas defined by the PDF417 symbol specifications).
GS ( k pL pH cn fn n (cn = 49, fn = 67)
[Name] QR Code: Set the size of module
[Format] ASCII GS ( k pL pH cn fn n
Hex 1D 28 6B pL pH cn fn n
Decimal 29 40 107 pL pH cn fn n
[Range] (pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 49
fn = 67
1 ≤ n ≤ 8
[Default] n = 3
[Description] • Sets the size of the module for QR Code to n dots.
GS ( k pL pH cn fn n (cn = 49, fn = 69)
[Name] QR Code: Select the error correction level
[Format] ASCII GS ( k pL pH cn fn n
Hex 1D 28 6B pL pH cn fn n
Decimal 29 40 107 pL pH cn fn n
[Range] (pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 49
fn = 69
48 ≤ n ≤ 51
[Default] n = 48
[Description] • Selects the error correction level for QR Code
n
Function
Reference: Approx. figure of recovery
48
Select error correction level L
7%
49
Select error correction level M
15%
50
Select error correction level Q
25%
51
Select error correction level H
30%
