GS ( k pL pH cn fn m d1…dk (cn = 49, fn = 80)
[Name] QR Code: Store the data in the symbol storage area
[Format] ASCII GS ( k pL pH cn fn m d1…dk
Hex 1D 28 6B pL pH cn fn m d1…dk
Decimal 29 40 107 pL pH cn fn m d1…dk
[Range] 4 ≤ (pL + pH × 256) <1021 (0 ≤ pL ≤ 255, 0 ≤ pH< 4)
cn = 49
fn = 80
m = 48
0 ≤ d ≤ 255
k = (pL + pH × 256) – 3
[Description] •Stores the QR Code symbol data (d1...dk) into the symbol storage area.
GS ( k pL pH cn fn m (cn = 49, fn = 81)
[Name] QR Code: Print the symbol data in the symbol storage area
[Format] ASCII GS ( k pL pH cn fn m
Hex 1D 28 6B pL pH cn fn m
Decimal 29 40 107 pL pH cn fn m
[Range] (pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 49
fn = 81
m = 48
[Description] • Encodes and prints the QR Code symbol data in the symbol storage area with GS
( k<Function 180>.
[Note] • User must secure the quiet zone (left, right, upward, and downward space areas defined
by the QR Code symbol specifications) for QR Code printing.
