Figure 5-11 Establishing the configuration environment over the WAN
WAN
Router
Target
Router
PC
Eth1/0/0
202.38.160.92/16
Configuration Roadmap
1. Establish the physical connection.
2. Set user login parameters.
3. Log in to the router from the client side.
Data Preparation
l IP address of the PC
l IP address of the Ethernet interface on the router
l User information (including the user name, password, and authentication mode)
l Reachable route between the PC and target router
Procedure
Step 1 Connect the PC and the router to the network.
Step 2 Set login user parameters on the target router.
# Configure the login address.
<Huawei> system-view
[Huawei] interface ethernet 1/0/0
[Huawei-Ethernet1/0/0] ip address 202.38.160.92 255.255.0.0
[Huawei-Ethernet1/0/0] quit
# Configure the login authentication mode
[Huawei] aaa
[Huawei-aaa] local-user huawei password cipher hello
[Huawei-aaa] local-user huawei service-type telnet
[Huawei-aaa] local-user huawei privilege level 3
[Huawei-aaa] quit
[Huawei] user-interface vty 0 4
[Huawei-ui-vty0-14] authentication-mode aaa
Step 3 Configure the client login.
Run the Telnet on the PC (use the Windows XP operating system as an example), as shown in
Figure 5-12.
