Huawei AR1200 Series - Example for Connecting the SFTP Client to the SSH Server

1 -rw- 396 Feb 11 2008 14:34:17 rsa_host_key.efs
2 -rw- 540 Feb 11 2008 14:35:10 rsa_server_key.efs
3 -rw- 1,498 Apr 01 2011 09:49:37 iascfg.zip
4 -rw- 525,337 Apr 01 2011 09:50:00 private-data.txt
5 -rw- 1,215 Mar 26 2011 11:32:27 iascfg_autobackup.zip
6 -rw- 1,703,936 Feb 27 2008 10:00:10 ar_smk2.cc
7 drw- - Mar 07 2008 15:44:46 dd
8 -rw- 69,143,936 Mar 28 2008 07:34:54 ar.cc
9 -rw- 8,996 Apr 07 2008 14:56:24 1.cap
10 -rw- 5,602 May 27 2011 13:59:31 ab.cap
11 -rw- 220 Mar 28 2011 16:51:16 elab.txt
12 -rw- 1,686 Mar 28 2011 17:04:53 lic_ar.dat
217,168 KB total (145,536 KB free)
Step 4 Log in to the router from the computer HyperTerminal and enter the following command to
upload a file.
<Huawei> tftp 10.111.16.160 put flash:/iascfg.zip
Info: Transfer file in binary mode.
Uploading the file to the remote TFTP server. Please wait...
TFTP: Uploading the file successfully.
3856 bytes send in 1 second.
----End
8.7.4 Example for Connecting the SFTP Client to the SSH Server
This example shows how to configure an SFTP client to connect to an SSH server. Local key
pairs are generated on the SFTP client and the SSH server, and a public RSA key is generated
on the SSH server and bound to the SFTP client.
Networking Requirements
As shown in Figure 8-9, after the SFTP service is enabled on the SSH server, the SFTP Client
can use the password, RSA, password-rsa, or all authentication mode to log in to the SSH server.
Figure 8-9 Networking diagram for connecting the SFTP client to the SSH server
Client002
Eth1/0/0
10.164.39.221/24
SSH Server
Eth1/0/0
10.164.39.222/24
Client001
Eth1/0/0
10.164.39.220/24
Configuration Roadmap
The configuration roadmap is as follows:
1. Configure Client001 and Client002 on the SSH server.
