Page #117 background image
NO TE
A rubber pad is installed in the mounting position to prevent cable tray burrs from scraping
cable sheathings.
Step 2 Carry the cables routed into a plastic coated metal hose onto the cable tray, and
bind them with cable ties.
NO TICE
The cables are long. Assign sucient people and ladders to carry the cables
onto the cable tray.
Before mounting cables on the cable tray, understand the installation
precautions and the regulations for working at heights, and put on necessary
protective equipment such as safety helmets and gloves.
After mounting cables on the cable tray, lay out the cables horizontally without
twists and bind the cables in proper positions with cable ties.
Reserve
sucient cable length and bending space when turning an armored
power cable.
If possible, place armored cables and thick cables on the outside and lower
layer of the cable tray.
Step 3 Cut the cable ties and adjust the cables.
NO TICE
The cable adjustment requirements are as follows:
The cable bend radius must meet requirements.
Fire control cables and monitoring cables must be placed in the inside on the
upper layer of cable trays.
Armored cables and power cables must be placed in the outside and bottom
layer of cable trays.
Cables must be level, without unevenness and
deection.
Step 4 After adjusting cables as required, bind them with cable ties.
NO TICE
Cables must be bound neatly, and cable ties must be secured evenly and properly
in the same direction.
----End
A.1.6 Routing Cables into Feeder Windows
DPJ end connectors and waterproof metal connectors are available on pre-fab.
module feeder windows. When routing cables through a feeder window, follow the
appropriate installation procedure.
FusionDC1000A Prefabricated All-in-One Data
Center
Installation Guide (IT Scenario) A Basic Installation Operations
Issue 01 (2021-04-20) Copyright © Huawei Technologies Co., Ltd. 110
