NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
992
Item
Specification
Minimum sending optical power (AVG)
(dBm)
0
Minimum sending optical power (OMA)
(dBm)
-
Working wavelength range of the optical
receiver (nm)
1270-1600
Receiving sensitivity (AVG) (dBm)
-24
Receiving sensitivity (OMA) (dBm)
-19.1
Saturated optical power (dBm)
-7
Minimum extinction ratio (dB)
9
Note
The interface standard is Huawei-specific.
Self-loop is not supported. An optical
attenuator must be added if self-loop is
required.
1.11.18 10Gbps XFP CWDM Optical Module
Figure 1-130 10Gbps XFP CWDM Optical Module
1.11.18.1 10Gbps-XFP-SMF-1611nm-70km-commercial
Table 1-1772 Technical specifications
Item
Specification
BOM
34060554
Model
XFP-LH70-SM1611
