Huawei NE40E User Manual

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
166
Indicator
Color
Normal
Status
Abnormal
Status
Abnormal
Reason
voltage.

The device
is powered
off due to
overcurrent
or short
circuit.

The current
of modules
is seriously
imbalanced.
Technical Specifications
Item
Specification
Dimensions (H x W x D)
41.5 mm x 107 mm x 437 mm(1.63 in x 4.21 in x 17.2
in)
Weight
2.0 kg(4.41 lb)
Rated input voltage
200 V AC to 240 V AC (220V)
240V DC/380V DC
Input voltage range
180 V AC to 264 V AC
192V DC to 400V DC
Maximum input current
16 A
Maximum output power
3000 W
Typical power consumption
182 W
Typical heat dissipation
590.5 BTU/hour
The AC power system supports 200-240 V AC power. It supports 110 V dual-live-wire inputs but not
110 V AC single-phase inputs. If 110 V dual-live-wire inputs are used, the voltage must range from 180
V to 264 V.
240V HVDC power system, the input voltage range from 192 V to 288 V DC. 380V HVDC power
system, the input voltage range from 260 V to 400 V.
1.8.6.7 AC PEM
The AC PEM is used to connect the AC power supply. Each PEM provides four power inputs.
The two terminals on the right side are connected to the power supply plane on the client side,
