Huawei NE40E - 1-Port 100 Gbase-CFP2 + 12-Port 10 Gbase LAN;WAN-SFP+ Integrated Line Processing Unit B(LPUI-240-B)

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
790
Attribute
Description
Frame format
Ethernet_II, Ethernet_SAP and Ethernet_SN/AP
Table 1-1447 Board specifications
Item
Specification
Dimensions (H x W x D)
40.1 mm x 399.2 mm x 535.6 mm (1.58 in. x 15.72 in. x
21.09 in.)
Typical power
consumption
346.0 W
Typical heat dissipation
1122.5 BTU/hour
Weight
10.6 kg (23.26 lb)
Ambient temperature
Long terms: 0 °C to 45 °C (32°F to 113°F) Short terms:
-5 °C to 55 °C (23°F to 131°F)
1.10.20.10 1-Port 100GBase-CFP2 + 12-Port 10GBase LAN/WAN-SFP+
Integrated Line Processing Unit B(LPUI-240-B)
Overview
Table 1-1448 Board attributes
Attribute
Description
Board name silkscreen
LPUI-240-B
1x100GBase-CFP2-12x10GBase
LAN/WAN-SFP+ -A
Description
1-Port 100GBase-CFP2 + 12-Port 10GBase
LAN/WAN-SFP+ Integrated Line Processing Unit
B(LPUI-240-B)
BOM
03057450
Model
CR5DE1NLBX71
Table 1-1449 Mapping products and versions
Product
Earliest Software Version
NE40E-X8
V800R009C10
