Huawei NE40E User Manual

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
866
Attribute
Description
Working mode
Full-duplex
Compliant
standard
IEEE 802.3
Frame format
Ethernet_II, Ethernet_SAP and Ethernet_SN/AP
Table 1-1661 Board specifications
Item
Specification
Dimensions (H x W x D)
40.1 mm x 399.2 mm x 535.6 mm (1.58 in. x 15.72 in. x
21.09 in.)
Typical power
consumption
584.5 W
Typical heat dissipation
1896.4 BTU/hour
Weight
11 kg (24.26 lb)
Ambient temperature
Long terms: 0 °C to 45 °C (32°F to 113°F) Short terms:
-5 °C to 55 °C (23°F to 131°F)
1.10.23.5 8-Port 100G ETH/DWDM-CFP2 Integrated Line Processing Unit
CM(LPUI-1T-CM)
Overview
Table 1-1662 Board attributes
Attribute
Description
Board name silkscreen
LPUI-1T-PC 8x100G
ETH/DWDM-CFP2
Description
8-Port 100G ETH/DWDM-CFP2 Integrated Line
Processing Unit CM(LPUI-1T-CM)
BOM
03057693
Model
CR5D00E8NC7P
