Huawei NE40E User Manual

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
281
Technical Specifications
Table 1-259 Board specifications
Item
Specification
Dimensions (H x W x D)
40.1 mm x 411 mm x 535.6 mm (1.58 in. x 16.18 in. x 21.09
in.)
Typical power
consumption
90.0 W
Typical heat dissipation
292.0 BTU/hour
Weight
4.3 kg (9.48 lb)
Ambient temperature
Long terms: 0 °C to 45 °C (32°F to 113°F) Short terms:
-5 °C to 55 °C (23°F to 131°F)
1.10.3.7 480Gbps Switch Fabric Unit B(SFUI-480-B)
Overview
Table 1-260 Board attributes
Attribute
Description
Board name silkscreen
SFUI-480-B
Description
480Gbps Switch Fabric Unit B(SFUI-480-B)
BOM
03055780
Model
CR5DSFUIM07B
Table 1-261 Mapping products and versions
Product
Earliest Software Version
NE40E-X16A
V800R006C20
