Huawei NE40E - 24-Port 10 Gbase LAN;WAN-SFP+ Integrated Line Processing Unit (LPUI-240)

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
769
Technical Specifications
Table 1-1390 Interface specifications
Attribute
Description
Optical type
supported
1.11.22 100Gbps CFP2 Optical Module
NOTE
When optical modules with the BOM number 02311LYG are used, 2x40G and
10x10G breakout optical fibers are not supported.
Working mode
Full-duplex
Compliant
standard
IEEE 802.3
Frame format
Ethernet_II, Ethernet_SAP and Ethernet_SN/AP
Table 1-1391 Board specifications
Item
Specification
Dimensions (H x W x D)
40.1 mm x 399.2 mm x 535.6 mm (1.58 in. x 15.72 in. x
21.09 in.)
Typical power
consumption
324.0 W
Typical heat dissipation
1051.3 BTU/hour
Weight
10.1 kg (22.27 lb)
Ambient temperature
Long terms: 0 °C to 45 °C (32°F to 113°F) Short terms:
-5 °C to 55 °C (23°F to 131°F)
1.10.20.3 24-Port 10GBase LAN/WAN-SFP+ Integrated Line Processing Unit
(LPUI-240)
Overview
Table 1-1392 Board attributes
Attribute
Description
Board name silkscreen
LPUI-240 24x10GBase
LAN/WAN-SFP+ -A
Description
24-Port 10GBase LAN/WAN-SFP+ Integrated Line
