Huawei NE40E User Manual

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
893
Item
Specification
Working case temperature (°C)
0 °C to 70 °C (32°F to 158°F)
Digital diagnosis
SFF-8472
Environment standard
RoHS
Security standard
FCC class B, IEC 60825-1 Class 1
ESD(HBM1) (V)
500
Transmission rate (bit/s)
1.25G
Connector type
LC
Transmission distance (km)
40
Optical fiber type
SMF
Center wavelength (nm)
1310
Working wavelength range of the optical
transmitter (nm)
1275-1350
Maximum sending optical power (AVG)
(dBm)
0
Maximum sending optical power (OMA)
(dBm)
-
Minimum sending optical power (AVG)
(dBm)
-5
Minimum sending optical power (OMA)
(dBm)
-
Working wavelength range of the optical
receiver (nm)
1260-1580
Receiving sensitivity (AVG) (dBm)
-23
Receiving sensitivity (OMA) (dBm)
-
Saturated optical power (dBm)
-3
Minimum extinction ratio (dB)
9.5
1.11.7.4 1.25Gbps-eSFP-SMF-1550nm-80km-commercial
Table 1-1686 Technical specifications
Item
Specification
BOM
34060360
Model
eSFP-1550nm-1000Base-Zx/FC100
