Huawei NE40E User Manual

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
249
Functional Specifications
Table 1-193 Functions and features
Functions and
Features
Remarks
Reliability and
availability
1:1 backup mode
Technical Specifications
Table 1-194 Board specifications
Item
Specification
Dimensions (H x W x D)
30 mm x 386.8 mm x 534.3 mm (1.18 in. x 15.23 in. x 21.04
in.)
Typical power
consumption
240.0 W
Typical heat dissipation
778.7 BTU/hour
Weight
6.3 kg (13.89 lb)
Ambient temperature
Long terms: 0 °C to 45 °C (32°F to 113°F) Short terms:
-5 °C to 55 °C (23°F to 131°F)
Processing unit
Quad-core 2.0GHz
SDRAM
8 GB x 1
Flash
16 MB
Storage
SSD card:8 GB
1.10.2.12 Switch and Route Processing Unit A9(16G Memory)
Overview
Table 1-195 Board attributes
Attribute
Description
Board name silkscreen
SRUA-1T-A
