Huawei NE40E - 5-Port 10 Gbase LAN;WAN-SFP+ Flexible Card a(P101-A)

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
619
Attribute
Description
Working mode
Full-duplex
Compliant
standard
IEEE 802.3
Frame format
Ethernet_II, Ethernet_SAP and Ethernet_SN/AP
Table 1-1024 Board specifications
Item
Specification
Dimensions (H x W x D)
37.2 mm x 178.7 mm x 193.3 mm (1.46 in. x 7.04 in. x 7.61
in.)
Typical power
consumption
37.0 W
Typical heat dissipation
120.0 BTU/hour
Weight
1 kg (2.2 lb)
Ambient temperature
Long terms: 0 °C to 45 °C (32°F to 113°F) Short terms:
-5 °C to 55 °C (23°F to 131°F)
1.10.15.11 5-Port 10GBase LAN/WAN-SFP+ Flexible Card A(P101-A)
Overview
Table 1-1025 Board attributes
Attribute
Description
Board name silkscreen
P101-5x10GBase LAN/WAN-SFP+
-A
Description
5-Port 10GBase LAN/WAN-SFP+ Flexible Card
A(P101-A)
BOM
03030PMK
Model
CR5D0L5XFA72
