Huawei NE40E User Manual

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
915
Item
Specification
Working case temperature (°C)
0 °C to 70 °C (32°F to 158°F)
Digital diagnosis
SFF-8472
Environment standard
RoHS
Security standard
FCC class B, IEC 60825-1 Class 1
ESD(HBM1) (V)
500
Transmission rate (bit/s)
2.5G
Connector type
LC
Transmission distance (km)
2
Optical fiber type
SMF
Center wavelength (nm)
1310
Working wavelength range of the optical
transmitter (nm)
1266-1360
Maximum sending optical power (AVG)
(dBm)
-3
Maximum sending optical power (OMA)
(dBm)
-
Minimum sending optical power (AVG)
(dBm)
-10
Minimum sending optical power (OMA)
(dBm)
-
Working wavelength range of the optical
receiver (nm)
1200-1650
Receiving sensitivity (AVG) (dBm)
-18
Receiving sensitivity (OMA) (dBm)
-
Saturated optical power (dBm)
-3
Minimum extinction ratio (dB)
8.5
1.11.10.2 2.5Gbps-eSFP-SMF-1310nm-15km-commercial
Table 1-1705 Technical specifications
Item
Specification
BOM
34060485
Model
eSFP-SM1310-155M~2.5G-15km
