NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
772
Attribute
Description
1.11.8 1.25Gbps eSFP BIDI Optical Module
1.11.11 125M~2.67Gbps eSFP DWDM Optical Module
1.11.12 10Gbps SFP+ Optical Module
1.11.13 10Gbps SFP+ CWDM Optical Module
1.11.14 10Gbps SFP+ BIDI Optical Module
1.11.15 10Gbps SFP+ DWDM Optical Module
Working mode
Full-duplex
Compliant
standard
IEEE 802.3
Frame format
Ethernet_II, Ethernet_SAP and Ethernet_SN/AP
Table 1-1399 Board specifications
Item
Specification
Dimensions (H x W x D)
40.1 mm x 399.2 mm x 535.6 mm (1.58 in. x 15.72 in. x
21.09 in.)
Typical power
consumption
347.0 W
Typical heat dissipation
1125.7 BTU/hour
Weight
10 kg (22.05 lb)
Ambient temperature
Long terms: 0 °C to 45 °C (32°F to 113°F) Short terms:
-5 °C to 55 °C (23°F to 131°F)
1.10.20.4 1-Port 100GBase-CFP + 12-Port 10GBase LAN/WAN-SFP+
Integrated Line Processing Unit (LPUI-240)
Overview
Table 1-1400 Board attributes
Attribute
Description
Board name silkscreen
LPUI-240 1x100GBase LAN-CFP
-12x10GBase LAN/WAN-SFP+ -A
Description
1-Port 100GBase-CFP + 12-Port 10GBase
LAN/WAN-SFP+ Integrated Line Processing Unit
(LPUI-240)
