Table 1-1401 Mapping products and versions
Earliest Software Version
Appearance
Panel
Table 1-1402 Buttons
Board removal button. To remove a board, hold down the OFL
button for about 6s until the OFL indicator turns on, and then remove
the board.
Table 1-1403 Indicators
If the indicator is steady on, the board can be removed.
If the indicator is steady on, the link is Up. If this indicator blinks,
data is being transmitted or received. If the indicator is off, the link is
Down.
If the indicator blinks once every 2s (0.5 Hz), the system is running
