Huawei NE40E User Manual

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
996
Item
Specification
Receiving sensitivity (AVG) (dBm)
-21
Receiving sensitivity (OMA) (dBm)
-
Saturated optical power (dBm)
-7
Minimum extinction ratio (dB)
8.2
1.11.18.4 10Gbps-XFP-SMF-1551nm-70km-commercial
Table 1-1775 Technical specifications
Item
Specification
BOM
34060551
Model
XFP-LH70-SM1551
Encapsulation mode
XFP
Interface standard
IEEE 802.3ae, 10GBASE-ZR/ZW;
STM64/OC-192
Bit Error Ratio (BER)
<1x10E–12
Working case temperature (°C)
0 °C to 70 °C (32°F to 158°F)
Digital diagnosis
SFF-INF-8077i
Environment standard
RoHS
Security standard
FCC class B, IEC 60825-1 Class 1
ESD(HBM1) (V)
500
Transmission rate (bit/s)
9.953G/10.3125G
Connector type
LC
Transmission distance (km)
70
Optical fiber type
SMF
Center wavelength (nm)
1551
Working wavelength range of the optical
transmitter (nm)
1544.5-1557.5
Maximum sending optical power (AVG)
(dBm)
4
Maximum sending optical power (OMA)
(dBm)
-
Minimum sending optical power (AVG)
(dBm)
0
