Huawei NE40E - 24-Port 1000 Base-X-SFP Flexible Card E(P52-E)

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
642
Attribute
Description
Compliant
standard
IEEE 802.3
Frame format
Ethernet_II, Ethernet_SAP and Ethernet_SN/AP
Table 1-1066 Board specifications
Item
Specification
Dimensions (H x W x D)
37.2 mm x 178.7 mm x 193.3 mm (1.46 in. x 7.04 in. x 7.61
in.)
Typical power
consumption
55.0 W
Typical heat dissipation
178.4 BTU/hour
Weight
1.2 kg (2.54 lb)
Ambient temperature
Long terms: 0 °C to 45 °C (32°F to 113°F) Short terms:
-5 °C to 55 °C (23°F to 131°F)
1.10.15.17 24-Port 1000Base-X-SFP Flexible Card E(P52-E)
Overview
Table 1-1067 Board attributes
Attribute
Description
Board name silkscreen
P52-24xGE-SFP-E
Description
24-Port 1000Base-X-SFP Flexible Card E(P52-E)
BOM
03031XQJ
Model
CR5D0EFGFE71
Table 1-1068 Mapping products and versions
Product
Motherboard
Earliest Software
Version for Flexible
Card
NE40E-X8
1.10.7.3 Flexible Card Line
Processing Unit(LPUF-51,2
V800R009C00
