1.9.6.4 Air Filter
A black sponge air filter on the air intake vent prevents dust from getting into the system. The
air filter can be removed and cleaned. Cleaning air filters once every three months is
recommended.
The NE40E-X16A has three air filters, the locations of which are shown in Figure 1-91.
Figure 1-91 Location of air filters
3. Air filter in the SFU area
The appearance of the air filter is shown in Figure 1-92.
