Huawei NE40E User Manual

NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
261
Functional Specifications
Table 1-214 Functions and features
Functions and
Features
Remarks
Reliability and
availability
1:1 backup mode
Technical Specifications
Table 1-215 Board specifications
Item
Specification
Dimensions (H x W x D)
40.1 mm x 399.2 mm x 535.6 mm (1.58 in. x 15.72 in. x
21.09 in.)
Typical power
consumption
90.0 W
Typical heat dissipation
292.0 BTU/hour
Weight
4.5 kg (9.92 lb)
Ambient temperature
Long terms: 0 °C to 45 °C (32°F to 113°F) Short terms:
-5 °C to 55 °C (23°F to 131°F)
Processing unit
Quad-core 2.0GHz
SDRAM
8 GB x 1
Flash
16 MB
Storage
SSD card:8 GB
1.10.2.15 Main Processing Unit B5(16G Memory)
Overview
Table 1-216 Board attributes
Attribute
Description
Board name silkscreen
MPUB5
Description
Main Processing Unit B5(16G Memory)
BOM
03057244
