NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
475
Table 1-705 Indicators
Name
Description
OFL (red)
If the indicator is steady on, the board can be removed.
L/A (green)
0 to 23 (green)
If the indicator is steady on, the link is Up. If this indicator blinks,
data is being transmitted or received. If the indicator is off, the link is
Down.
RUN (green)
If the indicator blinks once every 2s (0.5 Hz), the system is running
properly. If the indicator blinks twice every second (2 Hz), the board
is starting and has not completed registration.
Table 1-706 Service interfaces
Interface
Name
Interfac
e Type
Connec
tor
Type
Description
Cable
0/0 to 0/1
10G
LAN/WA
N
SFP+
Interface for
inputting and
outputting 10G
LAN/WAN
optical signals
Optical fiber and twisted pair
1/0 to 1/23
FE/GE
SFP
Interface for
inputting and
outputting
FE/GE optical
signals
Optical fiber and twisted pair
Functional Specifications
Table 1-707 Functions and features
Functions and
Features
Remarks
Line-Rate
capability
Supports 50G line-rate forwarding. One supports 2 x 10G line-rate
forwarding. The other provides 24 GE interfaces.
Reliability and
availability
Hot swappable.
Restrictions and
remarks
The 10G interfaces working in WAN mode can function only as
master interfaces.
