Panel
Table 1-1209 Buttons
Board removal button. To remove a board, hold down the OFL
button for about 6s until the OFL indicator turns on, and then remove
the board.
Table 1-1210 Indicators
If the indicator is steady on, the board can be removed.
If the indicator blinks once every 2s (0.5 Hz), the system is running
properly. If the indicator blinks twice every second (2 Hz), the board
is starting and has not completed registration.
Functional Specifications
Table 1-1211 Functions and features
Supports 200G line-rate forwarding.
The board provides a maximum of two half-width slots and each slot
can hold one FPIC.
Reliability and
availability
Technical Specifications
Table 1-1212 Board specifications
40.1 mm x 399.2 mm x 535.6 mm (1.58 in. x 15.72 in. x
21.09 in.)
Typical power
consumption
