4-Port 100GBase-CFP2 Integrated Line Processing Unit
B(LPUI-480-B)
Table 1-1583 Mapping products and versions
Earliest Software Version
Appearance
Panel
Table 1-1584 Buttons
Board removal button. To remove a board, hold down the OFL
button for about 6s until the OFL indicator turns on, and then remove
the board.
Table 1-1585 Indicators
If the indicator is steady on, the board can be removed.
If the indicator blinks once every 2s (0.5 Hz), the system is running
properly. If the indicator blinks twice every second (2 Hz), the board
is starting and has not completed registration.
