NE40E
Hardware Description
1 Hardware Description
Issue 01 (2018-05-03)
859
Name
Description
indicators are showing the running status of breakout channel 0 (if an
interface indicator is blinking, breakout channel 0 on this interface is
receiving and transmitting data); if breakout indicator 1 is on,
interface indicators are showing the running status of breakout
channel 1. If the board has breakout interfaces, each breakout
indicator for channels 0 to 9 turns on for 5s in sequence to indicate
the status of the corresponding channel. To rapidly identify the
running status of a specific breakout channel, press the Breakout
button to switch to your desired indicator. For example, if you want
to check the running status of breakout channel 1 on each interface,
press the Breakout button to have breakout indicator 1 turns on.
Table 1-1642 Service interfaces
Interface
Name
Interfac
e Type
Connec
tor
Type
Description
Cable
0 to 7
100GE
CFP2
Interface for
inputting and
outputting
100GE optical
signals
Optical fiber
Functional Specifications
Table 1-1643 Functions and features
Functions and
Features
Remarks
Line-Rate
capability
Supports 1T line-rate forwarding. It supports eight 100G interfaces
for line-rate forwarding.
Reliability and
availability
Hot swappable.
Technical Specifications
Table 1-1644 Interface specifications
Attribute
Description
Optical type
supported
1.11.22 100Gbps CFP2 Optical Module
NOTE
When optical modules with the BOM number 02311LYG are used, 2x40G
