HUAWEI TE80 Videoconferencing Endpoint
Administrator Guide
2 Basic Configuration and Verification
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
When the endpoint is powered on, ensure that the power cable is connected to the endpoint
securely to prevent power disconnection.
Before disconnecting the external power supply (for example, the power supply from a
power socket), power off the endpoint properly.
Check whether the power cable and the power adapter are connected to the relevant devices
properly. Ensure that:
The voltage of the alternating current ranges from 100 V to 240 V and the frequency of
the alternating current ranges from 50 Hz to 60 Hz.
The sequence of and voltage difference between the live wire, neutral wire, and ground
cable comply with the relevant international standards. In addition, ensure that the
ground cable is properly grounded.
To power on the endpoint, slide the power switch on the rear panel to the ON position.
To power off the endpoint, perform either of the following operations:
Press on the remote control. Confirm the power-off action in the displayed dialog
box.
Slide the power switch on the rear panel to the OFF position.
When the endpoint is powered off using the remote control, the indicator on the front panel turns orange,
but the power switch on the rear panel is still in the ON position. To power on the endpoint again, press
on the remote control.
Depending on the endpoint's status, the indicators on the front panel may blink in different
colors and at different rates, as listed in Table 2-1 and Table 2-2.
Table 2-1 Status indicator description
When the Status Indicator
Is...
Blinking blue twice per second
Blinking purple once every 2
seconds
Powered off (the power switch is ON, and the endpoint
is powered off by pressing on the remote
control).
Responding to a remote control operation.
Blinking blue four times per
second
To Next Page
