(7) RS485/RS232 port (8) Fast Ethernet (FE) port (9) CAN communications port
(10) LCD
Indicators
Table 3-12 Indicator description
Name Color Status Description
Run
indicator
Green O The SMU is faulty or has no DC
input.
Blinking
slowly (0.5
Hz)
The SMU is running properly and
communicating with the host
properly.
Blinking fast
(4 Hz)
The SMU is running properly but fails
to communicate with the host
properly.
Minor alarm
indicator
Yellow O No minor or warning alarm is
generated.
Steady on A minor or warning alarm is
generated.
Major alarm
indicator
Red O No critical or major alarm is
generated.
Steady on A critical or major alarm is
generated.
Buttons
Table 3-13 Button description
Button
Name Description
Up
Press and to scroll through the menus or to
change the value of a parameter.
Down
Cancel Returns to the previous menu without saving the
settings.
Enter ● Enters the main menu from the standby screen.
● Enters a submenu from the main menu.
● Saves menu settings on a submenu.
PowerCube 1000 (STC, Saudi Arabia, ICC800-A1-C2,
ESC800-A1)
Installation Guide 3 Component
Issue 02 (2021-09-28) Copyright © Huawei Technologies Co., Ltd. 37
