Huawei SUN2000-3KTL-M1 User Manual

Technical
Specicatio
ns
SUN2000-3
KTL-M1
SUN2000-4
KTL-M1
SUN2000-5
KTL-M1
SUN2000-6
KTL-M1
SUN2000-8
KTL-M1
SUN2000-1
0KTL-M1
Rated
output
voltage
220 V/380 V, 230 V/400 V, 3W+N+PE
Maximum
output
voltage at
long-term
operation
See standards about the local power grid.
Rated
output
current
4.6 A (380
V)/
4.4 A (400
V)
6.1 A (380
V)
/5.8 A (400
V)
7.6 A (380
V)/
7.3 A (400
V)
9.1 A (380
V)/
8.7 A (400
V)
12.2 A (380
V)
/11.6 A
(400 V)
15.2 A (380
V)/
14.5 A (400
V)
Maximum
output
current
5.1 A 6.8 A 8.5 A 10.1 A 13.5 A 16.9 A
Output
voltage
frequency
50 Hz/60 Hz
Power
factor
0.8 leading–0.8 lagging
Maximum
total
harmonic
distortion
(THD)
AC THDi
< 3% under rated conditions. Single harmonic meets the VDE4105 requirements.
Protection
Technical
Specicatio
ns
SUN2000-3
KTL-M1
SUN2000-4
KTL-M1
SUN2000-5
KTL-M1
SUN2000-6
KTL-M1
SUN2000-8
KTL-M1
SUN2000-1
0KTL-M1
Overvoltag
e category
PV II/AC III
Input DC
switch
Supported
Islanding
protection
Supported
SUN2000-(3KTL-10KTL)-M1
User Manual 10 Technical Specications
Issue 02 (2020-11-20) Copyright © Huawei Technologies Co., Ltd. 99

Huawei SUN2000-3KTL-M1 Specifications

General

Model	SUN2000-3KTL-M1
Type	String Inverter
Max. DC Input Voltage	600 V
MPPT Voltage Range	90 V - 560 V
Rated AC Output Power	3000 W
Max. AC Output Power	3300 W
Nominal AC Voltage	220 V / 230 V / 240 V
AC Voltage Range	180 V - 280 V
AC Output Frequency	50 Hz / 60 Hz
Max. Efficiency	98.6%
MPPT Trackers	2
DC Inputs per MPPT	1
Max. Input Current per MPPT	11 A
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Protection Degree	IP65
Max. DC Input Power	4500 W
Communication	RS485
Dimensions (W x H x D)	365 mm x 365 mm x 156 mm
