5.7.5 Connecting a Signal Cable to the Smart Backup Box
Procedure
Step 1 Connect the signal cable to the signal cable connector.
Figure 5-32 Installing the cable
Step 2 Connect the signal cable connector to the COM port.
Figure 5-33 Securing the signal cable connector
----End
