Huawei SUN2000-3KTL-M1 User Manual

NO TE
There are two types of Smart Dongle.
● For details about how to operate the WLAN-FE Smart Dongle SDongleA-05, see
SDongleA-05 Quick Guide (WLAN-FE). You can also scan the QR code to obtain the
document.
● For details about how to operate the 4G Smart Dongle SDongleA-03, see SDongleA-03
Quick Guide (4G). You can also scan the QR code to obtain the document.
The quick guide is delivered with the Smart Dongle.
5.7 (Optional) Connecting the Signal Cable
COM Port Pin Denitions
NO TICE
● When laying out the signal cable, separate it from the power cable and keep it
away from strong interference sources to avoid strong communication
interference.
● Ensure that the protective layer of the cable is inside the connector, that excess
core wires are cut
o from the protection layer, that the exposed core wire is
totally inserted into the cable hole, and that the cable is connected securely.
SUN2000-(3KTL-10KTL)-M1
User Manual 5 Electrical Connections
Issue 02 (2020-11-20) Copyright © Huawei Technologies Co., Ltd. 48

Huawei SUN2000-3KTL-M1 Specifications

General

Model	SUN2000-3KTL-M1
Type	String Inverter
Max. DC Input Voltage	600 V
MPPT Voltage Range	90 V - 560 V
Rated AC Output Power	3000 W
Max. AC Output Power	3300 W
Nominal AC Voltage	220 V / 230 V / 240 V
AC Voltage Range	180 V - 280 V
AC Output Frequency	50 Hz / 60 Hz
Max. Efficiency	98.6%
MPPT Trackers	2
DC Inputs per MPPT	1
Max. Input Current per MPPT	11 A
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Protection Degree	IP65
Max. DC Input Power	4500 W
Communication	RS485
Dimensions (W x H x D)	365 mm x 365 mm x 156 mm
