Huawei SUN2000-3KTL-M1 User Manual

D Rapid Shutdown
NO TE
● If optimizers are congured for some PV modules, the rapid shutdown function is not
supported.
● You are advised to periodically check whether the rapid shutdown function is normal.
When all PV modules connected to the solar inverter are
congured with
optimizers, the PV system shuts down quickly and reduces the output voltage of
the PV string to below 30 V within 30 seconds.
Perform the following step to trigger rapid shutdown:
● Method 1: To enable the rapid shutdown function, you need to connect the
access switch to pins 13 and 15 of the SUN2000 communications terminal.
The switch is closed by default. The rapid shutdown is triggered when the
switch changes from closed to open.
● Method 2: Turn
o the AC switch between the solar inverter and the power
grid.
● Method 3: Set the DC switch at the bottom of the SUN2000 to OFF. (Turning
o an extra switch on the DC side of the SUN2000 will not trigger rapid
shutdown. The PV string may be energized.)
SUN2000-(3KTL-10KTL)-M1
User Manual D Rapid Shutdown
Issue 02 (2020-11-20) Copyright © Huawei Technologies Co., Ltd. 113

Huawei SUN2000-3KTL-M1 Specifications

General

Model	SUN2000-3KTL-M1
Type	String Inverter
Max. DC Input Voltage	600 V
MPPT Voltage Range	90 V - 560 V
Rated AC Output Power	3000 W
Max. AC Output Power	3300 W
Nominal AC Voltage	220 V / 230 V / 240 V
AC Voltage Range	180 V - 280 V
AC Output Frequency	50 Hz / 60 Hz
Max. Efficiency	98.6%
MPPT Trackers	2
DC Inputs per MPPT	1
Max. Input Current per MPPT	11 A
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Protection Degree	IP65
Max. DC Input Power	4500 W
Communication	RS485
Dimensions (W x H x D)	365 mm x 365 mm x 156 mm
