Figure 4-13 Determining the positions for drilling holes
Step 2 Drill holes using a hammer drill.
You are advised to apply anti-rust paint on the hole positions for protection.
Figure 4-14 Drilling holes
Step 3 Secure the mounting bracket.
SUN2000-(3KTL-10KTL)-M1
User Manual 4 Installation
Issue 02 (2020-11-20) Copyright © Huawei Technologies Co., Ltd. 28
