Huawei TE40 Administrator's Guide

HUAWEI TE40&TE50&TE60 Videoconferencing
Endpoint
Administrator Guide
B Technical Specifications
Issue 01 (2013-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
157
Catego
ry
Item
Specifications
features
VideoIntensifier
ViewProcessing
Facial Recognition
The TE40 and TE50 support the following:

dual 1080p60 (presentation mode: presentation)

1080p60+1080p30 (presentation mode: live)
The TE60 supports the following: dual 1080p60
(presentation modes: presentation or live)
Audio
Input

TE40: 1 x XLR, 2 x RCA, 1 x microphone array
HD-AI port, and 1 x HDMI port (supporting audio
input)

TE50: 1 x XLR, 2 x RCA, 1 x microphone array
HD-AI port, 1 x 3.5 mm, and 1 x HDMI port
(supporting audio input)

TE60: 2 x XLR, 2 x RCA, 1 x microphone array
HD-AI port, 1 x HDMI port (supporting audio input),
and 1 x DisplayPort (supporting audio input)
Output

TE40: 4 x RCA port and 2 x HDMI port (supporting
audio output)

TE50: 4 x RCA port and 2 x HDMI port (supporting
audio output)

TE60: 4 x RCA port, 2 x HDMI port (supporting audio
output), and 2 x DVI-I (output using DVI-HDMI
conversion cables)
Audio processing
AEC, ANS, and AGC
Networ
k port
Network port
2 x 10/100/1000 M LAN, 1 x Wi-Fi, 1 x 4 E1 connector
(optional, only for the TE60), and 1 x PSTN (Only
available in China)
USB
port
USB
2 × USB 2.0
COM
port
COM
2 × COM
Periphe
rals
VPC600 and VPC620 HD cameras
Endpoint control by using the camera to forward infrared signals
VPM220 and VPM220W microphone arrays
The TE40 and TE50 can be connected to only one VPM220 or VPM220W
microphone array. The TE60 can be connected to up to two VPM220 or
VPM220W microphone arrays.
Electric
ity
Operating voltage
and frequency
100 V AC–240 V AC; 50 Hz–60 Hz;
