Huawei TE40 Administrator's Guide

HUAWEI TE40&TE50&TE60 Videoconferencing
Endpoint
Administrator Guide
2 Basic Configuration and Verification
Issue 01 (2013-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
15
If you have selected the Enable GK or Register with server parameter and set other required
parameters but the endpoint fails to register with the GK or SIP server, or is
displayed in the lower right corner of the call screen.
Verification Result

If you successfully place a call to the remote site using its IP address, the IP network is
functioning properly.

If you successfully place a call to an H.323 site, the endpoint has registered with the GK
server.

If you successfully place a call to a SIP site, the endpoint has registered with the SIP
server.
2.3.2 Sound Test
By performing a sound test, you can check whether the audio input and output of the endpoint
is correct.
Prerequisites

The endpoint has been connected to an audio input device such as a microphone.

The endpoint has been connected to an audio output device, such as a speaker, or
connected to a television using an HDMI cable.
Procedure
Step 1 Choose Advanced > Diagnostics > Sound and Color Bar Test from the option bar.
Step 2 Select Sound Test.
----End
Verification Result

If the speaker emits a "ding ding" tone when there is no audio input, the audio output of
the endpoint is correct.

If audio inputs, for example human voices, are received from the microphone and the
speaker emits the voices, the audio input and output of the endpoint are correct.
2.3.3 Image Test
By performing an image test, you can check whether the video input and output of the
endpoint is correct.
Prerequisites
The endpoint has been connected to video sources and a display device.
