5 Microphone and Speaker
Issue 01 (2013-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
62
Step 3 Select Save.
----End
5.1.2 Connecting a VPM220W
The endpoint can be connected to a HUAWEI VPM220W wireless microphone array
(VPM220W) over a Wi-Fi network. The TE50 and TE40 can be connected to only one
VPM220W while the TE60 can be connected to one or two VPM220Ws.
When installing a VPM220W, do not point any microphone towards the speaker.
Status Indicators on the VPM220W
VPM220W status indicators quickly provide VPM220W working status.
There are five indicators on top of the VPM220W and a charging status indicator on the
charger base. Table 5-6 describes these indicators.
Table 5-6 Status indicators on the VPM220W
Indicator Status
VPM220W Work Status
All three microphone indicators are steady
red.
All the three microphones are turned off.
All three microphone indicators are steady
blue.
All the three microphones are turned on.
All three microphone indicators are off.
The power switch of the VPM220W is turned
off.
All three microphone indicators are blue
on and off gradually.
The VPM220W is in sleep state.
All three microphone indicators are
blinking blue in a clockwise direction.

The VPM220W is connecting to the
videoconferencing endpoint.

The VPM220W is restarting.
All three microphone indicators are
blinking blue twice simultaneously.
The VPM220W is preparing to send a
videoconferencing endpoint a request for
Wi-Fi Protected Setup (WPS) Push Button
Configuration (PBC) authentication.
All three microphone indicators are
blinking blue simultaneously.
The VPM220W is upgrading.
All three microphone indicators are
blinking red twice in a clockwise direction.
The VPM220W is about to power off.
The Wi-Fi indicator is off.

The VPM220W is powered off.

The VPM220W is connecting to a
videoconferencing endpoint over Wi-Fi,
and the Wi-Fi signal is strong.
The Wi-Fi indicator is steady red.
The VPM220W is connecting to a
videoconferencing endpoint over Wi-Fi, and
