Huawei TE40 Administrator's Guide

HUAWEI TE40&TE50&TE60 Videoconferencing
Endpoint
Administrator Guide
6 Conference
Issue 01 (2013-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
72
One display device: Based on the default endpoint settings, the display device connected to
the 1 MAIN OUT port can show the video, presentation, remote controlled UI, captions, and
combined pictures.
Two display devices: To show the video and presentation independently on two display
devices, connect the two to the 1MAIN OUT and 2 PC OUT ports if you are using the TE60
or to the 1 MAIN OUT and 2 HDMI OUT ports if you are using the TE50 or TE40. A display
device shows the video when connected to the 1 MAIN OUT port and shows the presentation
when connected to the 2 PC OUT port (or 2 HDMI OUT port). The Dual-screen parameter
must be enabled in order for this to work. For details, see 4.2.1 Configuring Video Output.
6.1.2 Sharing a Presentation
A computer can be connected to the endpoint to share files, and the remote sites can view both
your video and the desktop contents of the computer.
Prerequisites
The video source of the presentation has been configured.
The presentation sharing function has been enabled, and the presentation parameters have
been set. By default, the endpoint has the presentation sharing function enabled, and the
default presentation parameter settings support presentation sharing. To modify these
parameters, see 13.3 Setting Advanced Conference Parameters.
Background
You can select either of the following modes for sharing a presentation:

Auto: The endpoint automatically sends the video along with the presentation. This
mode is available only when Presentation mode is set to Live.

Manual: You can use the remote control to share a presentation.
For details, see Table 13-3 in 13.3 Setting Advanced Conference Parameters.
However, in live mode, the endpoint does not support presentation sharing using SIP.
On a Microsoft unified communications (MSUC) network, the endpoint does not support
presentation sharing.
Procedure
Press on the remote control to share a presentation.
To stop sharing a presentation, press on the remote control.
you can also select on the option bar to share a presentation.
6.1.3 Viewing the Combined Picture of the Presentation and the
Video
During a conference, a combined picture of the video and the presentation can be viewed by
pressing on the remote control or selecting from the option bar.
