Hubbell GAI-TRONICS E3 Console Manual

Pub. 42004-550A
Elemec3 Console Manual—Version 3.0 Page 4 of 114
P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-550A.docx
09/20
Define the System’s Zones
Action
Screen
Add zones.
Zones (on page 69)
Enter the zone description.
Assign the audio outputs to the zone:
• Monitor Output
• Aux Output
Assign the amplifier channels to the zone.
Assign relay outputs to the zone.
Assign relay groups to the zone.
Assign logic flags to the zone.
Zone Configuration → Zone Builder screen
(on page 70)
Configure the Background Music Source
Action
Screen
Select the audio input source (Aux 1–5).
Select the zone where background music will play.
Select the time interval for amplifier testing.
Playback Audio → Background Music
(on page 74)
Import Sound Files for Pre-Recorded Messages
Action
Screen
Browse and select an .mp3 file.
Import the .mp3 file it into the configuration file.
Playback Audio → Import MP3
(on page 73)
Define System Tones
Action
Screen
Select an .MP3 sound file for a system tone (1–7).
Enter a description for a system tone (1–7).
Select an .MP3 sound file for the “TICK TONE”.
Set the play volume for each system tone.
Playback Audio → System Tones
(on page 73)
Add Messages
Action
Screen
Add a new message. Enter a message description.
Playback Audio → Add Message (on page
72)
Event Setup—Select automatically create events and
the manual and/or auto event check boxes.
Select the default zone for the message to play in.
Configure automatic logic flag setup.
Create New Message
(on page 72)
Select the .mp3 sound files to include in the message.
Message Builder (on page 74)
