170 ArcGlide THC Instruction Manual 806450
4 – Maintenance
Figure 44
3. Load a small grease gun with a needle-type adapter with lithium base grease. (Castrol Longtime
®
PD2 or equivalent
is recommended.) To lubricate with a hand press, weigh out the quantity of grease in each stroke.
4. Inject 0.7 g (0.025 oz) of grease into one of the lubrication nipples. If you are using the Hypertherm grease gun
(428259), one pump of the gun is equivalent to 0.7 g (0.025 oz). You do not need to lubricate the carriage on both
sides.
