60 ArcGlide THC Instruction Manual 806450
2 – Installation
System description for a discrete configuration
Figure 12 shows the cable and signal connections in a discrete communication configuration.
For information on multi-drop configurations, refer to the instruction manual for your plasma system.
Figure 12
Customer-supplied operator console
(optional):
Station on/off/program switch
Station active light
Lifter UP/DOWN switch
CNC
Plasma system
ArcGlide lifter
HMI (optional)
ArcGlide control module
Key:
Hypernet connection
– – – – – –
Discrete connection
——————
