Discrete communication
In a discrete configuration, signals are routed through the ArcGlide control module. Each component in the configuration,
except the HMI, is connected to the ArcGlide control module with discrete cables. The HMI communicates with the
control module using the Hypernet protocol over a shielded, Ethernet Cat5e or Cat6 cable.
Figure 8
Lifter
Plasma system
Picopath CNC ArcGlide control module Plasma interface board
HMI
Key:
Hypernet connection
Discrete connection
