266 ArcGlide THC Instruction Manual 806450
A – ArcGlide THC Serial Communication Protocol
ArcGlide THC to Command THC error conversions
The ArcGlide THC supports a broad error message set. When you are using the ArcGlide THC as a replacement for the
Command THC, ArcGlide error codes are converted into Command THC error codes, and only the Command THC error
codes are returned with the EC command.
When you are using the ArcGlide THC in a new installation and using the ArcGlide extended command set:
ArcGlide errors can be returned using the AE command.
The actual ArcGlide errors will always be displayed on the ArcGlide control module and HMI displays.
These errors are for reference. See ArcGlide errors on page 191 for a definition of each error and suggestions
for corrective action.
Table 9 – ArcGlide errors and equivalent Command THC errors
ArcGlide Command THC
Error Code Error Message Error Code Description
0 NO ERRORS 16 ERR-NO ERROR
1 ERR 1 FLASH SETUPS 2 ERR-EEPROM checksum Error
2 ERR 2 MAX SPEED EXCEEDED 4 ERR-Motion FAIL
3 ERR 3 LIFTER HOME TIMEOUT 4 ERR-Motion FAIL
4 ERR 4 PLATE CONTACT AT HOME 7 ERR-Nozzle Contact at Home
5 ERR 5 HOME LIM DURING OPR 1 ERR-Torch is in HOME LIMIT
6 ERR 6 LOWER LIM DURING OPR 0 ERR-Torch is in LOWER LIMIT
7 ERR 7 FAILED MOVE TO CROSSOVER 4 ERR-Motion FAIL
8 ERR 8 FAILED TO CONTACT PLATE 4 ERR-Motion FAIL
9 ERR 9 FAILED TO CLEAR PLATE 4 ERR-Motion FAIL
10 ERR 10 FAILED MOVE TO XFER HT 4 ERR-Motion FAIL
11 ERR 11 IHS SYNC TIMEOUT 5 ERR-Watchdog timeout FAIL
12 ERR 12 TRANSFER TIMEOUT 5 ERR-Watchdog timeout FAIL
13 ERR 13 LOST TRANSFER 11 ERR-Plasma Cable Missing
14 ERR 14 FAILED MOVE TO PIERCE 4 ERR-Motion FAIL
15 ERR 15 FAILED MOVE CUTHEIGHT 4 ERR-Motion FAIL
16 ERR 16 RAMPDOWN TIMEOUT 5 ERR-Watchdog timeout FAIL
